Features & Benefits

100 to 500 MHz Bandwidths

5 GS/s Maximum Real-time Sample Rate, with sin(x)/x Interpolation

3,600 wfms/s Continuous Waveform Capture Rate

2 or 4 Channels

Full VGA Color LCD

25 Automatic Measurements

FFT Standard

Multi-language User Interface

QuickMenu Graphical User Interface for Easy Operation

WaveAlert® Automatic Waveform Anomaly Detection

OpenChoice® Solutions Simplify Instrument Control, Documentation, and Analysis

e*Scope® Web-based Remote Control

Built-in Ethernet port

GPIB, RS232, VGA

TDSPCS1 OpenChoice Software

WaveStar™ Software

Integration with Third-party Software

Application Modules for Specialized Analysis

Advanced Analysis Module

Limit Testing Module

Telecommunications Mask Testing Module

Extended Video Module

601 Serial Digital Video Module

Optional Internal Battery Operation up to 3 Hours Without Line Power

Plug-in Printer for Portable Documentation of Results

TekProbe® Interface Supports Active, Differential, and Current Probes for Automatic Scaling and Units
