Features:

Resolution bandwidth: 1 Hz to 10 MHz

Displayed average noise level: -155 dBm (1 Hz)

Phase noise: -113 dB (1 Hz) at 10 kHz

Total measurement uncertainty: 0.5 dB

Measurement routines for TOI, ACP(R), OBW, CCDF, APD, etc. as standard

Additional filters: Channel filters from 100 Hz to 5 MHz and RRC filters, FFT filters from 1 Hz to 30 kHz, EMI bandwidths and quasi-peak detector

Measurement applications for cellular standards and general purpose, e.g. phase noise, noise figure, etc.

DANL typ.: -155 dBm (1 Hz) w/o preamp

Phase-noise typ.: -113 dBc/Hz @ 10 kHz offset, CF 500 MHz

Phase-noise typ.: -145 dBc/Hz @ 10 MHz offset, CF 500 MHz

TOI typ.: 10 dBm

1-dB-compression point: 0 dBm

0.5 dB total level uncertainty up to 3.6 GHz

<0.2 dB linearity error down to -70 dB

IF digitizer 12 bit 32 MHz (20.4 MHz IF)

IQ memory 2x128 ksamples

2.5ms sweep time in frequency domain

1 µs sweep time in time domain

Up to 70 remote measurements/s via GPIB

Up to 80 manual measurements/s (screen update)
