Features & Benefits

350 MHz Bandwidth Model

2 Channel Model

2.5 GS/s on All Channels

10 Megasample Record Length on All Channels

50,000 wfms/s Maximum Waveform Capture Rate

Wave Inspector® Controls Provide Unprecedented Efficiency in Waveform Analysis

I2C, SPI, CAN, LIN, FlexRay and RS-232/422/485/UART Serial Triggering and Analysis Options

10.4 in. (264 mm) XGA Color Display

Small Footprint and Lightweight - only 5.4 in. (137 mm) deep and 11 lbs. (5 kg)!

USB and CompactFlash on Front Panel for Quick and Easy Storage

Built-in Ethernet Port

Plug ‘n’ Play Connectivity and Analysis Software Solutions

USB 2.0 Device Port for Direct PC Control of Oscilloscope using USBTMC

Suite of Advanced Triggers

e*Scope® Remote Viewing and Control

Interoperability with Tektronix Logic Analyzers

TekVPI™ Probe Interface Supports Active, Differential and Current Probes for Automatic Scaling and Units

HDTV and Custom Video Trigger Option
