2651A SourceMeter

Keithley 2651A High Power System SourceMeter (SMU) Instrument, 50A/40V/2000W Channels: 1 Max Current Source/Measure Range: 50A Max Voltage Source/Measure Range: 40V Measurement Resolution (Current / Voltage): 100fA / 100nV Power: 2000 W Easily connect two units (in series or parallel) to create solutions up to ±100 A or ±80 V 1 pA resolution enables precise measurement of very low leakage currents 1 µs per point (1 MHz), 18-bit sampling, accurately characterizes transient behavior 1% to 100% pulse duty cycle for pulse width modulated (PWM) drive schemes and device- specific drive stimulus Combines a precision power supply, current source, DMM, arbitrary waveform generator, V or I pulse generator with measurement, electronic load, and trigger controller all in one instrument
