SourceMeter
Brand：Keithley
Name：SourceMeter
Model：2611B
Condition：Second Hand
Delivery Time：5Day
Warranty Period：30Day
Address：China
Whether to Measure：No
Teleconference
Product Details
Keithley 2611B System SourceMeter SMU — Product Introduction
The Keithley 2611B is a single-channel System SourceMeter SMU from the 2600B series. It integrates a precision power supply, true current source, 6½-digit digital multimeter, arbitrary waveform generator, pulse generator, and electronic load into one compact instrument.
Key Specifications
Channels: Single channel
Maximum Voltage: 200 V
Maximum Current: 1.5 A DC / 10 A pulse
Maximum Output Power: 30 W DC / 200 W pulse
Measurement Resolution: 100 fA / 100 nV, 6½ digits
Voltage Accuracy: 0.015%
Operating Modes: 4-quadrant source/measure
Interfaces: USB 2.0, GPIB, LXI Ethernet, RS-232, TSP-Link, Digital I/O
Dimensions: 238 mm (W) x 104 mm (H) x 460 mm (D), approximately 4.75 kg
